The AB 1756-IF6C is an isolated current-to-voltage converter designed for precise and reliable data acquisition in industrial control systems. Its high accuracy and robust performance make it ideal for applications requiring precise analog signal conversion.
Measurement Range:4 mA to 20 mA
Input Type:Isolated Current
Resolution:0.02 mA
Accuracy:+/- 0.02% of full scale + 2 LSB
Power Supply:12 to 36 VDC
Communication Interface:ControlNet
Environmental Conditions:Temperature range: -40°C to 85°C, Humidity: 5 to 95% non-condensing
Enclosure Rating:IP20
Operating Voltage:24 VDC
Output Signals:4 to 20 mA, 0 to 10 V
Operating Frequency:50 Hz
Communication Rate:500 kbps
Dimensions:90 x 90 x 65 mm
Weight:0.2 kg
The AB 1756-IF6C is engineered with precision in mind, featuring a ±20mA input range capable of accurately converting currents into voltage signals, essential for various industrial control processes.
This module boasts an electrical isolation design, ensuring safe operation in harsh industrial environments and preventing electrical interference between different parts of the system.
With its wide operating temperature range from -40°C to +85°C, the 1756-IF6C is suitable for diverse industrial applications, making it a versatile choice for global operations.
Equipped with a 0-10V DC output voltage range, this converter ensures compatibility with a variety of downstream devices, facilitating seamless integration into existing control systems.
Featuring a low power consumption of up to 3W, the AB 1756-IF6C conserves energy and reduces operational costs, aligning with modern sustainability goals without compromising on performance.
The AB 1756-IF6C is an isolated current-to-voltage converter designed for precise and reliable data acquisition in industrial control systems. Its high accuracy and robust performance make it ideal for applications requiring precise analog signal conversion.
