ABB 5SNS 0100W120000 IGBT Module – Advanced Power Control Solutions
Technology:IGBT
Model Number:5SNS 0100W120000
Rated Current:100A
Operating Voltage:DC 1200V
Switching Frequency:Up to 15kHz
Cooling Method:Thermal Pad & Heat Sink
Package Type:TO-247
Operating Temperature Range:-40°C to +175°C
Certifications:[“CE”,”UL”,”IEC”]
Introducing the ABB 5SNS 0100W120000, an advanced IGBT (Insulated Gate Bipolar Transistor) module engineered to deliver unparalleled performance in industrial power conversion tasks. This module is meticulously designed to handle the most challenging conditions, ensuring reliability and efficiency across a wide range of applications.
Featuring a robust power rating of 1000W and a voltage rating of 1200V DC, this module is capable of handling heavy loads while maintaining optimal performance. Its current rating of 800A allows for seamless operation in power-intensive environments.
Equipped with a switching frequency of 20kHz, the ABB 5SNS 0100W120000 ensures fast response times and efficient energy transfer, making it ideal for applications requiring rapid and precise control. Its low thermal resistance of ≤2.5°C/W ensures efficient heat dissipation, maximizing system uptime.
The module employs a thermal pad and heat sink for effective cooling, ensuring optimal performance even under high operating temperatures ranging from -40°C to +175°C. This broad temperature range makes it suitable for various industrial settings worldwide.
Safety is paramount with the ABB 5SNS 0100W120000. It comes with built-in protection against overcurrent, overvoltage, and overheating, safeguarding against potential failures and extending the lifespan of the module. Additionally, its insulation class F provides enhanced electrical safety.
Discover the future of industrial power conversion with the ABB 5SNS 0100W120000 IGBT module. Its combination of high power density, superior reliability, and advanced protection features makes it an indispensable component for modern industrial systems.
