The ABB LF1005-S Inverter Current Transformer is a high-precision instrument designed for accurate current measurement in industrial automation systems, ensuring reliable control and monitoring.
Measurement Range:Up to 600A
Accuracy:+/- 1% (Max.)
Frequency Response:45 Hz – 500 Hz
Operating Temperature:-20°C to +60°C
Protection Class:IP20
Output Signal:0-5V DC or 4-20mA
Connection Type:Terminal Block
Supply Voltage:DC 12V
Load Resistance:1 kΩ
Material:High-grade Ferromagnetic Alloy
The ABB LF1005-S Inverter Current Transformer is designed for applications requiring high precision and reliability in current measurement. Its robust construction ensures durability and long-lasting performance in industrial environments.
Featuring a wide measurement range up to 600A, this transformer is suitable for various industrial applications including motor control, power distribution, and process control systems.
With an impressive accuracy of ±0.5%, the LF1005-S guarantees reliable data for critical decision-making processes, ensuring optimal system efficiency and safety.
Operable within a temperature range of -20°C to +50°C, this transformer is ideal for use in a variety of climates without compromising performance. Its IP20 protection class offers basic splash and dust resistance.
The terminal block connection allows for easy integration into existing electrical systems, while the high-grade copper and iron alloy material ensures efficient current transfer and reduced power loss.
For seamless operation, the LF1005-S operates at 50Hz frequency and can handle an AC 230V operating voltage, making it compatible with a wide range of industrial equipment.
