The Allen Bradely 1398-DDM-075 Servo Drive Module is a high-performance, versatile AC servo drive designed for precise control in a wide range of industrial automation applications. It efficiently manages motor power, optimizing performance and ensuring smooth operation across various environments.
Input Voltage Range:100-240V AC
Operating Frequency:47-63Hz
Peak Output Current:7.5A
Torque Range:2.3-12.4 Nm
Output Current Flow Max:500mA
SERCOS Interface Compatibility:Yes
Ambient Temperature Range:-40°C to 70°C
Relative Humidity Range:5% to 95%
Size:Dimensions: 4.2 x 5.1 x 1.7 inches
Integrating advanced technology, the Allen Bradely 1398-DDM-075 Servo Drive delivers unparalleled performance and precision. Its 7.5A peak output current and torque range from 0.34 to 50.8Nm ensures smooth operation across diverse industrial applications.
With its SERCOS interface, this servo drive effortlessly connects with leading machine control systems like SLC and Logix devices, facilitating seamless integration and enhancing overall efficiency.
Designed for robust performance, the 1398-DDM-075 is equipped to handle demanding industrial environments. Its wide ambient temperature range (-40 to 70°C) and relative humidity range (5 to 95%) ensure reliability under varied conditions.
Featuring an internal shunt resistance of 16.5 Amps and a bus capacitance of 4290 µF with a bus overvoltage value of 452V DC, this servo drive is built to withstand the rigors of industrial use while maintaining stable operation.
For optimal performance, we recommend maintaining the drive within a clean, well-ventilated cabinet to prevent dust accumulation. Ensuring proper clearance around the servo drive is essential for safety and longevity.
The Allen Bradely 1398-DDM-075 Servo Drive Module is a high-performance, versatile AC servo drive designed for precise control in a wide range of industrial automation applications. It efficiently manages motor power, optimizing performance and ensuring smooth operation across various environments.
