The GE SR745-W2-P5-G5-HI is an advanced transformer protection system designed to safeguard transformers, autotransformers, and reactors. It features a user-friendly interface and robust technical specifications to ensure reliable operation in industrial environments.
Model Number:745-W2-P5-G5-HI-A-E-H
Windings Per Phase:2
Resistant Temperature Device (RTD):3 wire; 100 Ω Nickel, 120 Ω Nickel, 100 Ω Platinum
Analog Output Maximum Load:10 kΩ at 0 to 1 mA, 600 Ω at 4 to 20 mA
Maximum Continuous Voltage Output:273 V
Display Type:40 character Enhanced LCD
Dimensions:Height: 9″, Width: 7″, Depth: 7 ⅛”
Control Power Range:90 to 300 V DC; 70 to 265 V AC at 48 to 62 Hz
