The GE SR750 750-P5-G5-D5-HI-A20-R-E Electric Motor Management Relay is an advanced component designed for critical industrial applications. It ensures seamless motor operation and protection by monitoring and managing electrical currents and voltage levels.
Communications Baud Rate:300 to 19200 baud
Frequency Range:25 to 60 Hz nominal
Operating Environment:Humidity up to 90% non condensing
Overvoltage Pickup Level:0 to 1.25 × VT in steps of 0.01
Relay Dimensions:Approx. 18cm W, 16.5cm L, 21.5cm H
Waveform Capture Channels:4 currents, 3 voltages, 14 logic input states and 8 output relays
Number of Setpoint Groups:4
Analog Input Impedance:375 Ω ± 10%
Case and Relay Weight:7.9kg
Red Breaker Closed LED:Visible status indicator
Insulation Voltage:300 V
Manual Overvoltage Pickup Adjustment:Adjustable from 0 to 1.25 × VT in steps of 0.01
Equipped with state-of-the-art technology, the GE SR750 750-P5-G5-D5-HI-A20-R-E Electric Motor Management Relay boasts an ultra-compact design that fits seamlessly into any industrial control panel. Its robust construction ensures reliable performance under harsh conditions.
With its high-speed communication capabilities, the relay facilitates efficient data exchange between the motor and the control system, enhancing overall operational efficiency. The relay’s ability to monitor multiple parameters simultaneously provides unparalleled control over the motor’s health and performance.
The inclusion of an enhanced faceplate option offers improved user interface accessibility, making it easier for operators to configure settings and troubleshoot issues. This feature significantly reduces downtime and maintenance costs.
Featuring a manual override function (Manual 1601-0120-AE), users can easily switch the relay to bypass automatic controls, ensuring safety during critical maintenance procedures or unexpected situations.
Backed by GE’s commitment to quality and innovation, the GE SR750 750-P5-G5-D5-HI-A20-R-E Electric Motor Management Relay is the ideal choice for applications requiring high reliability and precision. Experience the peace of mind that comes with industry-leading protection for your motor systems.
