The Molex 85003-0567 is a high-performance industrial connector module designed for reliable data transmission in demanding environments. Ideal for industrial automation systems, it ensures robust connectivity and durability.
Connector Type:High-Speed Data Connector
Contacts:24 positions
Current Rating:1.5A per contact
Voltage Rating:500V
Operating Temperature:-40°C to 105°C
Contact Plating:Gold over nickel
Cable Size:24-30 AWG
Material:High-grade thermoplastic
The Molex 85003-0567 Connector Assembly is engineered for robust performance in demanding industrial settings. Its rugged design includes a high-quality thermoplastic housing that ensures durability and long-lasting use. With an IP67 rating, it provides excellent protection against dust and water ingress, making it ideal for outdoor installations and harsh environments. The connector supports a wide range of wire gauges from 22-16 AWG, accommodating various wiring needs. Designed with safety in mind, it boasts a voltage rating of up to 500V and a current rating of 15A, ensuring reliable power transmission. Operating temperatures can range from -40°C to 105°C, allowing for stable performance even in extreme conditions. Installation is straightforward, thanks to its user-friendly design and clear labeling. This connector assembly is an essential component for any industrial automation system, providing secure and dependable connections that enhance overall system reliability.
