The Schneider Electric M238 TM2DRA16RT Analog Input Module is an advanced, high-performance component designed for seamless integration into industrial control systems, offering unparalleled accuracy and reliability.
Number of Inputs:16
Signal Type:Analog
Sampling Rate:Up to 1 kHz
Operating Voltage:DC 24V
Communication Protocol:Modbus RTU
Environmental Conditions:Operating Temperature: -20°C to +70°C, Storage Temperature: -40°C to +85°C
Dimensions:128mm x 128mm x 104mm
Weight:Approx. 0.5kg
Connectors:2 x M12 x 24-pin
Relay Outputs:0 (for Analog Input)
The Schneider Electric TM2DRA16RT Analog Input Module is an essential component for any industrial control system requiring precise analog signal acquisition. Its robust design ensures durability and reliability in harsh environments.
Featuring 16 independent channels, this module allows for flexible configuration to suit various industrial applications, from temperature monitoring to flow rate control.
With a wide operating temperature range of -20°C to +60°C, it’s suitable for use in diverse industrial settings, ensuring continuous performance regardless of ambient conditions.
The module supports DC 24V power supply and utilizes the Modbus RTU communication protocol, enabling seamless integration with existing PLC (Programmable Logic Controller) systems.
Equipped with an M238 connector type, it offers efficient and secure connection, while its IP20 enclosure rating protects against dust and minor water splashes, enhancing its longevity and safety in industrial operations.
The Schneider Electric M238 TM2DRA16RT Analog Input Module is an advanced, high-performance component designed for seamless integration into industrial control systems, offering unparalleled accuracy and reliability.
