Schneider TSX08ED12RD Expansion Module

Number of Inputs/Outputs:8 Inputs / 12 Outputs

Operating Voltage:DC 24V

Communication Protocol:Modbus RTU

Operating Temperature Range:-20°C to +60°C

Dimensions (WxHxD):120mm x 96mm x 90mm

Connectors:M12 x 10-pin connector

Relay Rating:250VAC, 1A @ 250VAC, 0.5A @ 24VDC

Operating Humidity Range:5% to 95% non-condensing

    Engineered with precision for industrial environments, the Schneider TSX08ED12RD Expansion Module significantly enhances system capabilities by providing a robust platform for data acquisition and control.

    Featuring 8 high-precision analog input channels, this module allows for the accurate measurement of various electrical parameters, making it ideal for applications requiring detailed process monitoring.

    With 12 digital relay outputs, the TSX08ED12RD enables precise control over machinery and processes, ensuring smooth operation and efficient management of industrial tasks.

    The module supports Modbus RTU communication, facilitating easy integration with existing control systems and simplifying network setup for streamlined data exchange.

    Designed for extreme conditions, this expansion module operates reliably within a wide temperature range (-20°C to +70°C) and maintains stable performance even under varying humidity levels (5% to 95% RH), ensuring continuous operation in diverse industrial settings.
