The Schneider Electric TSXAEZ801 is an 8-channel analog input module designed for precise voltage measurement within industrial automation systems, supporting versatile applications across manufacturing, processing, and control environments.
Number of Channels:8
Analog Input Range:0-10 V
Current Consumption:Max. 60 mA
Conversion Resolution:12-bit
Electrical Connection:Terminal Block
Operating Temperature:-25°C to +60°C
Mounting Style:Panel Mount
Input Resistance:2 kΩ
Output Type:Open Collector
Protection Class:IP20
The Schneider TSXAEZ801 is designed for high accuracy and reliability, making it ideal for applications requiring precise analog signal processing. This 8-channel module ensures stable and dependable operation in a wide range of industrial environments.
With its versatile 0-10 V input range, the TSXAEZ801 can seamlessly integrate with various sensors and devices, facilitating seamless data collection and analysis in manufacturing, process control, and automation systems.
Featuring a compact yet robust design, the module supports both panel and DIN rail mounting options, providing flexibility in installation across different machinery and equipment setups.
The Schneider TSXAEZ801 comes equipped with advanced circuitry to minimize interference and noise, ensuring the integrity of the analog signals. Its low current consumption makes it energy-efficient, reducing operational costs without compromising performance.
Built for durability, the TSXAEZ801 operates within an extended temperature range (-25°C to +60°C), suitable for use in demanding industrial settings. Its IP20 protection rating safeguards against dust and light splashes, enhancing its reliability in various environments.
The Schneider Electric TSXAEZ801 is an 8-channel analog input module designed for precise voltage measurement within industrial automation systems, supporting versatile applications across manufacturing, processing, and control environments.
